Engineering the Future of Space & Defense with Hybrid Propulsion Systems
At Space Zone Aerospace, we develop cutting-edge space and defense technologies, including hybrid propulsion launch vehicles, advanced missile systems, and next-generation satellite solutions. Our products are designed to serve commercial space missions, defense applications, and scientific research with a focus on efficiency, sustainability, and cost-effectiveness.
Rhumi Series – Hybrid Propulsion Launch Vehicles
The Rhumi Series consists of high-performance hybrid rockets, designed for satellite launches, research missions, and strategic payload deployment. Our hybrid propulsion technology combines solid and liquid fuel advantages, ensuring efficiency, safety, and reduced environmental impact.
Key Advantages
Sustainable, cost-efficient, and next-gen propulsion for space and defense applications.
Rhumi-1
- Rocket Type: Single-Stage Hybrid Sounding Rocket
- Apogee: Up to 80 km (Suborbital Trajectory)
- Propulsion: LOX / SZA-HRF-80 (Hybrid Engine)
- Maximum Thrust: 25 | 40 | 65 kN
- Payload Capacity: 10 | 25 | 50 kg
- Rocket Dimensions: L x D – 5 m x 212 mm
- Lift-Off Mass: Approx. 80 – 150 kg
- Recovery System: Parachute
- Launch Platform: Mobile / Compact Fixed Launch Pad
- Launch Readiness: < 6 Hours (Rapid Deployment)
- Environmental Impact: Low Emissions, Clean Hybrid Propulsion
Rhumi-2
- Rocket Type: Single-Stage Suborbital Hybrid Launcher
- Apogee: Up to 250 km (Suborbital Trajectory)
- Propulsion: LOX / SZA-HRF-250 (Hybrid Engine)
- Maximum Thrust: 70 | 95 | 112 kN
- Specific Impulse (Isp): ~245 seconds (Vacuum)
- Payload Capacity: 50 | 100 | 200 kg
- Fairing Size: L x B – 1.80 x 0.98 m
- Rocket Dimensions: L x D – 6.2 m x 640 | 840 | 1540 mm
- Lift-Off Mass: Approx. 320 kg
- Launch Platform: Mobile / Fixed Launch Pad
- Launch Readiness: < 12 Hours (Rapid Deployment)
- Environmental Impact: Green Propulsion – Low Emissions, No Toxic Effluents
Rhumi-3
- Rocket Type: Two-Stage Suborbital Launcher
- Stage 1: Hybrid Propulsion (LOX / SZA-HRF-700) | Stage 2: Liquid Propulsion (Pressure-Fed System)
- Apogee: Up to 700 km (Suborbital Trajectory)
- Thrust: Stage 1: 1850 kN | Stage 2: 243 kN Burn Time: Stage 1: 95.5 seconds | Stage 2: 153 seconds
- Payload Capacity: 150 / 250 / 400 kg
- Inclination Angles Supported: 30°, 45°, 60°, 70°
- Rocket Dimensions: L x D - 11.5 x 1.25 m
- Lift-Off Mass: Approx. 2,400 – 2,700 kg
- Guidance System: INS + GPS + Optional AI-Based Correction
- Launch Platform: Fixed Heavy-Duty Launch Pad
- Launch Readiness: < 24 Hours (Pre-Integrated & Modular Design)
Hybrid Propulsion Systems
We specialize in hybrid propulsion technology, which offers higher safety, controllability, and reusability than traditional solid or liquid fuel systems.
- Eco-friendly hybrid propellant combinations.
- Greater mission flexibility and reduced operational costs.
- Improved reusability for sustainable space operations.
Applications
- Satellite Launch Systems – Optimized for efficiency and scalability.
- Missile Technology – High-performance propulsion for defense.
- Future Space Mobility – Enabling next-gen reusable space vehicles.
Key Advantages
Enhanced performance with lower emissions and cost savings.
Dhran-H – Advanced Hybrid Missile System
The Dharan Series is an advanced missile system which is one of our key and vital space missile system
Key Advantages
A high-performance hybrid missile designed for modern warfare.
DHRAN HX 1
- Warhead: High-Explosive
- Range: 10 to 35 km
- Speed: Supersonic (Mach 1.5 - 2)
- Launch Platform: Mobile Launcher / Fixed Launch Pad
- Guidance System: GPS
- Missile Type: Surface-to-Surface (SSM), Air-to-Surface (ASM), Surface-to-Air (SAM), Air-to-Air (AAM), Sea-to-Surface (SSM), Sea-to-Air (SAM).
DHRAN ATHM 50
- Warhead: Conventional / High-Explosive / Smart Payload
- Range: 500 to 1000 km
- Speed: Supersonic (Mach 4 - 4.5)
- Guidance System: GPS, Inertial Navigation System (INS), AI-Based Targeting
- Launch Platform: Fixed Launch Pad
- Missile Type: Surface-to-Surface (SSM)
DHRAN PRAHAR
- Warhead: High-Explosive / Smart Payload
- Range: 50 to 400 km
- Speed: Supersonic (Mach 2.5 - 3.2)
- Guidance System: GPS, Inertial Navigation System (INS)
- Launch Platform: Fixed Launch Pad
- Missile Type: Surface-to-Surface (SSM)
Why to choose SpaceZone Aerospace?
Space Zone Aerospace is committed to strengthening defense capabilities through state and work in mobile systems throughout for protection, speed, and strategic documents.
End-to-End Aerospace & Defense Solutions
Covering launch systems, palpation, and defense
Cost Effective & Suitable
Affordable solutions for space access and defense
High Freedom & Reliability
State-of-the-art engineering for mission success
Hybrid Propulsion Expertise
Advancing sustainable and efficient propulsion technologies
Sustainability & Reusability Focus
Eco-friendly and trust-give space technologies
What makes Space Zone Aerospace stand out
Space Zone Aerospace is committed to strengthening defense capabilities through state-of-the-art remote systems deployed for precision, speed, and strategic deterrence.
Reach out to Us!
Have questions or want to collaborate? We’d love to hear from you! Connect with us for inquiries on launch services, partnerships, and innovations.
Let’s shape the future of aerospace together!🚀
